Marantz SR5300 - Page 61

83
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
SR6300
POS. NO
VERS.
COLOR
PART NO.
(FOR EUR)
DESCRIPTION
PART NO.
(MJI)
MAIN PCB
BEAD101
*FC500010R *FC500010R BEAD,COIL BAS3580T0 3.5PHI*8 52RE 7610035800020
BEAD105
C101 *OF100250R *OF100250R C,FILM POLYESTER RED-0.1µF-K/250V-5RE D02010407H080
C102 *OF100300R *OF100300R C,FILM POLYESTER ST-0.047µF-J/100V-5RE D02047306C060
C103 *OF100300R *OF100300R C,FILM POLYESTER ST-0.047µF-J/100V-5RE D02047306C060
C104x *OF100260R *OF100260R C,FILM POLYESTER RED-0.1µF-K/63V-5RE D020104078060
C105x *OF100260R *OF100260R C,FILM POLYESTER RED-0.1µF-K/63V-5RE D020104078060
C106 *OF100250R *OF100250R C,FILM POLYESTER RED-0.1µF-K/250V-5RE D02010407H080
C107 *OF100250R *OF100250R C,FILM POLYESTER RED-0.1µF-K/250V-5RE D02010407H080
C108
*OF100300R *OF100300R C,FILM POLYESTER ST-0.047µF-J/100V-5RE D02047306C060
C111
C114 *EX000130R *EX000130R C,ELECT GE 85C 2200µF-M/35V,18*35.5 BULK(SNAPIN) SAGUB D040222085240
C115 *EX000130R *EX000130R C,ELECT GE 85C 2200µF-M/35V,18*35.5 BULK(SNAPIN) SAGUB D040222085240
C116 nsp nsp C,CERAMIC HIK DISC B0.01µF-K/50V-5RE D004103277050
C117 *EX000100R *EX000100R C,ELECT GE 85C 10000µF-M/16V,18*35L.BLK SY D040104083000
C118 *EX000120R *EX000120R C,ELECT GE 85C 2200µF-M/16V,12.5*20 D040222083210
C119 *EA001140R *EA001140R C,ELECT GE 85C 15000µF-M/71V 35*75 BULK(SNAPIN) SAGUB D040153089310
C120 *EA001140R *EA001140R C,ELECT GE 85C 15000µF-M/71V 35*75 BULK(SNAPIN) SAGUB D040153089310
C121 nsp OA10605020 CAP.E.GENERIC 10µF/50V(M) 5x11,P=5(LUXON-GR) 85,2000H N211210078110
C122 *OF100250R *OF100250R C,FILM POLYESTER RED-0.1µF-K/250V-5RE D02010407H080
C123 *OF100250R *OF100250R C,FILM POLYESTER RED-0.1µF-K/250V-5RE D02010407H080
C124 nsp nsp C,CERAMIC HIK DISC B0.01µF-K/50V-5RE D004103277050
C125
nsp OA10505020 CAP.E.GENERIC 1µF/50V(M) 5x11,P=5(LUXON-GR) 85,2000H N211210978110
C129
C132 nsp OA10702520 CAP.E.GENERIC 100µF/25V(M) 6.3x11,P=5(LUXON-GR) 85,2000H N211210148110
C135 nsp nsp C,CERAMIC HIK AXIAL F0.1µF-Z/50V-52RE D005104597530
C140 nsp OA47505020 CAP.E.GENERIC 4.7µF/50V(M) 5x11,P=5(LUXON-GR) 85,2000H N211247978110
C141 nsp OA47701620 CAP.E.GENERIC 470µF/16V(M) 8x11,P=5(LUXON-GR) 85,2000H N211247138110
C142 nsp OA47701620 CAP.E.GENERIC 470µF/16V(M) 8x11,P=5(LUXON-GR) 85,2000H N211247138110
C143 nsp nsp C,CERAMIC HIK AXIAL F0.1µF-Z/50V-52RE D005104597530
C144 nsp nsp C,CERAMIC HIK AXIAL F0.1µF-Z/50V-52RE D005104597530
C145 nsp OA10610020 CAP.E.GENERIC 10µF/100V(M) 6.3x11,P=5(LUXON-GR) 85,2000H N2112100C8110
C146 nsp OA47601050 CAP.E.GENERIC 47µF/10V(M) 5X11,P=5(LUXON-GR) 85,2000H N211247028110
C147 nsp nsp C,CERAMIC HIK AXIAL F0.1µF-Z/50V-52RE D005104597530
C148 nsp nsp C,CERAMIC HIK AXIAL F0.1µF-Z/50V-52RE D005104597530
C148A nsp nsp C,CERAMIC HIK AXIAL B0.001µF-K/50V-52RE D005102177530
C149 nsp OA47505020 CAP.E.GENERIC 4.7µF/50V(M) 5x11,P=5(LUXON-GR) 85,2000H N211247978110
C150 nsp OA47601640 CAP.E.GENERIC 47µF/16V(M) 5x11,P=5(LUXON-GR) 85,2000H N211247038110
C151 *EX000080R *EX000080R C,ELECT GE 85C 8200µF-M/5.5V SY D040822080010
C152 nsp nsp C,CERAMIC HIK AXIAL B100pF-K/50V-52RE D005101177520
C153 /N nsp nsp C,CERAMIC HIK AXIAL F0.1µF-Z/50V-52RE D005104597530
C154 /N nsp nsp C,CERAMIC T.C DISC CH27pF-J/50V-5RE D00027016705C
C155 /N nsp nsp C,CERAMIC T.C DISC CH27pF-J/50V-5RE D00027016705C
C156 /N nsp OA10605020 CAP.E.GENERIC 10µF/50V(M) 5x11,P=5(LUXON-GR) 85,2000H N211210078110
C157 /N nsp nsp C,CERAMIC HIK AXIAL B270pF-K/50V-52RE D005271277520
C158 /N nsp OA47601640 CAP.E.GENERIC 47µF/16V(M) 5x11,P=5(LUXON-GR) 85,2000H N211247038110
C159 /N nsp nsp C,CERAMIC SEMI DISC F0.1µF-Z/50V-5RE PI6 D006104597050
IC108 /N *HC107330R *HC107330R IC,ANALOG TDA7330BD-SOP20P /RDS DEMODULATOR J080733000010
J121
/N nsp nsp CN,WIRE 1P JUMPER (0.6/52MM) L045084006040
J263
C160
nsp nsp C,CERAMIC HIK AXIAL B100pF-K/50V-52RE D005101177520
C163
C164 nsp nsp C,CERAMIC HIK AXIAL B220pF-K/50V-52RE D005221277520
C164A nsp nsp C,CERAMIC HIK AXIAL F0.1µF-Z/50V-52RE D005104597530
C169
nsp nsp C,CERAMIC HIK AXIAL F0.047µF-Z/50V-52RE D005473597520
C173
C174 nsp OA22702520 CAP.E.GENERIC 220µF/25V(M) 8x11,P=5(LUXON-GR) 85,2000H N211222148110
