84
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
SR6300
POS. NO
VERS.
COLOR
PART NO.
(FOR EUR)
DESCRIPTION
PART NO.
(MJI)
CN101 nsp nsp CN.WAFER 2.5MM 5267-06A 6P L102526700600
CN102 nsp nsp CN.WAFER 3.96MM 35328-0310 L104353280300
CN103 nsp nsp CN.WAFER 2.5MM 5267-03A 3P L102526700300
CN104 nsp nsp CN.WAFER 2.5MM 5267-10A 10P L102526701000
CN105 nsp nsp CN.WAFER 2.5MM 5267-09A 9P L102526700900
CN107 nsp nsp CN.WAFER 2.5MM PLUG BD,BD 53421-1317 13P 2.5 ST ZIP L102534211310
CN108 nsp nsp CN.WAFER 2.0MM TUC-P20P-B1 BD-TO-BD 20P WAFER ST L101100042010
CN109 nsp nsp CN.WAFER 2.0MM TUC-P20P-B1 BD-TO-BD 20P WAFER ST L101100042010
CN110 nsp nsp CN.WAFER 2.0MM TUC-P10P-B1 BD-TO-BD 10P WAFER ST L101100041010
CN111 nsp nsp CN.WAFER 2.0MM TUC-P16P-B1 BD-TO-BD 16P WAFER ST L101100041610
CN112 nsp nsp CN.WAFER 2.0MM TUC-P14P-B1 BD-TO-BD 14P WAFER ST L101100041410
CN113 nsp nsp CN.WAFER 2.0MM TUC-P14P-B1 BD-TO-BD 14P WAFER ST L101100041410
CN114 nsp nsp CN.WAFER 2.0MM TUC-P16P-B1 BD-TO-BD 16P WAFER ST L101100041610
CN115 nsp nsp CN.WAFER 2.0MM TUC-P18P-B1 BD-TO-BD 18P WAFER ST L101100041810
CN116 nsp nsp CN.WAFER 2.0MM TUC-P16P-B1 BD-TO-BD 16P WAFER ST L101100041610
CN117 nsp nsp CN.WAFER 2.0MM TUC-P20P-B1 BD-TO-BD 20P WAFER ST L101100042010
CN118 nsp nsp CN.WAFER 2.0MM 35336-1310 13P L101353361310
CNT106 nsp nsp CN,WIRE 240MM/4P YH396-4XB3951H03*2 TWIST L000241040010
CNT119 nsp nsp CN,WIRE 420MM/4P GIL-S-4=9073-4 WH1007#26 L000421040010
D101
nsp *HD201570R D,SWITCHING IN4007 52REEL 1000V 1A K000400700520
D105
D106A *HE200310R *HE200310R D,RECTIFIER BRIDGE DIODE BRIDGE GBJ1006 600V/10A K047100600010
D107A *HE200310R *HE200310R D,RECTIFIER BRIDGE DIODE BRIDGE GBJ1006 600V/10A K047100600010
D108 nsp *HD201570R D,SWITCHING IN4007 52REEL 1000V 1A K000400700520
D109 nsp *HD201570R D,SWITCHING IN4007 52REEL 1000V 1A K000400700520
D110 nsp *HD201720R D,SWITCHING 1N4148-52RE 75V 150MA DO-34 (MIC) K000414803520
D110A nsp *HD201720R D,SWITCHING 1N4148-52RE 75V 150MA DO-34 (MIC) K000414803520
D111 nsp *HD201570R D,SWITCHING IN4007 52REEL 1000V 1A K000400700520
D113
nsp *HD201720R D,SWITCHING 1N4148-52RE 75V 150MA DO-34 (MIC) K000414803520
D129
FPC101 *YU000930R *YU000930R CABLE FLAT CARD FPC23P FPC101A&FPC101B L301241230010
FPC101A nsp nsp CN.FPC 1.25MM 8370-231 23P ST L131837002300
GND101
nsp nsp TERMINAL ALL PBST/GND PLATE-REEL 3790040876010
GND107
IC101 HC38915090 HC38915090 IC,LINEAR-REGULATOR MC7815CT TO220 (ON SEMI)(METAL TYPE) J126781500070
IC102 *HC300200R *HC300200R IC,LINEAR-REGULATOR KIA7915PI,20W-TO220IS MOLD J126791500030
IC103 HC38905090 HC38905090 IC,LINEAR-REGULATOR MC7805CT TO220 (ON SEMI)(METAL TYPE) J126780500380
IC104 HC38905090 HC38905090 IC,LINEAR-REGULATOR MC7805CT TO220 (ON SEMI)(METAL TYPE) J126780500380
IC105 *HC300190R *HC300190R IC,LINEAR-REGULATOR KIA7905PI,20W-TO220IS MOLD J126790500070
IC106 *HC400020R *HC400020R IC,LOGIC CD4094BCN DIP16 /8BIT SHIFT REGISTER J040409400050
IC107 *HU100610R *HU100610R IC,CPU CXP740010-163Q DWP586 QFP100 /SR5300 J020740010163
J101
nsp nsp CN,WIRE 1P JUMPER (0.6/52MM) L045084006040
J300
Q101 *HT100340R *HT100340R SEMI,TR/GE PNP 2SA KTA1268BL,0.3W/TO92-REEL J5001268B0050
Q102 *HT700050R *HT700050R SEMI,TR/GE NPN 2SC KTC3200BL,0.6W/TO92-REEL J5023200B0050
Q103 *HT100340R *HT100340R SEMI,TR/GE PNP 2SA KTA1268BL,0.3W/TO92-REEL J5001268B0050
Q104 *HT100340R *HT100340R SEMI,TR/GE PNP 2SA KTA1268BL,0.3W/TO92-REEL J5001268B0050
Q105 *HT700050R *HT700050R SEMI,TR/GE NPN 2SC KTC3200BL,0.6W/TO92-REEL J5023200B0050
Q106 *HT100340R *HT100340R SEMI,TR/GE PNP 2SA KTA1268BL,0.3W/TO92-REEL J5001268B0050
Q107 *HT700050R *HT700050R SEMI,TR/GE NPN 2SC KTC3200BL,0.6W/TO92-REEL J5023200B0050
Q108
*BA001190R *BA001190R SEMI,BRT/NPN RC KRC107M,0.4W/TO92M-REEL J6020107M0010
Q112
Q115 *HT700050R *HT700050R SEMI,TR/GE NPN 2SC KTC3200BL,0.6W/TO92-REEL J5023200B0050
Q116 *HT700050R *HT700050R SEMI,TR/GE NPN 2SC KTC3200BL,0.6W/TO92-REEL J5023200B0050
Q117 *HT100340R *HT100340R SEMI,TR/GE PNP 2SA KTA1268BL,0.3W/TO92-REEL J5001268B0050
Q118 *HT100340R *HT100340R SEMI,TR/GE PNP 2SA KTA1268BL,0.3W/TO92-REEL J5001268B0050
Q119 *HT700050R *HT700050R SEMI,TR/GE NPN 2SC KTC3200BL,0.6W/TO92-REEL J5023200B0050
Q120 *HT700050R *HT700050R SEMI,TR/GE NPN 2SC KTC3200BL,0.6W/TO92-REEL J5023200B0050
Q122 *BA001210R *BA001210R SEMI,BRT/PNP RA KRA102M,0.3W/TO92M-REEL J6002202M0010
