SR7001 RS-232C Control Specification Page: 9 / 19
Document Version [1.0]
Company Restricted
5. Definitions of Command, Status and Layer
This section is told how to define “Command”, “Status” and “Layer” of this product.
5-1. Normal Command List
This chapter will show the commands of this product.
5-1-1. Main function contents
Command Reply from Slave
TOGGLE “PWR:0”
OFF “PWR:1”
POWER
ON “PWR:2”
“PWR:1”,
“PWR:2”
TOGGLE “ATT:0”
OFF “ATT:1”
AUDIO ATT
ON “ATT:2”
“ATT:0”, (None)
“ATT:1”, (OFF)
“ATT:2” (ON)
TOGGLE “AMT:0”
OFF “AMT:1”
AUDIO MUTE
ON “AMT:2”
“AMT:1”,
“AMT:2”
TOGGLE “VMT:0”
OFF “VMT:1”
VIDEO MUTE
ON “VMT:2”
“VMT:1”,
“VMT:2”
VALUE “VOL:0xxxy”
UP “VOL:1”
DOWN “VOL:2”
UP-FAST “VOL:3”
VOLUME
DOWN-FAST “VOL:4”
“VOL:xxxy”
xxx = vol. value as +18~-80db, y = .0 or .5
db
00.0 = ”VOL: 000”,
-∞ = “VOL:-ZZZ”
VALUE “TOB:0xxx”
UP “TOB:1”
TONE BASS
DOWN “TOB:2”
“TOB:xxx”
xxx = vol. value as +06 ~-06
VALUE “TOT:0xxx”
UP “TOT:1”
TONE TREBLE
DOWN “TOT:2”
“TOT:xxx”
xxx = vol. value as +06 ~-06
TV “SRC:1”
DVD “SRC:2”
VCR1 “SRC:3”
DSS/VCR2 “SRC:5”
AUX1 “SRC:9”
AUX2 “SRC:A”
CD/CD-R “SRC:C”
TAPE “SRC:E”
TUNER1 “SRC:F”
FM1 “SRC:G”
AM1 “SRC:H”
SOURCE
Select
XM1 “SRC:J”
“SRC:va”, (v ,a= ‘0’ ~ ‘Z’)
(v = video, a = audio.)
v = 0 (V-OFF)
a = N (7.1CH)
TOGGLE “71C:0”
OFF “71C:1”
7.1 Channel
Input
ON “71C:2”
“71C:1”,(OFF)
“71C:2”(ON)
Command Reply from Slave
SPKR SEL “SPK:0”
SPKR-A OFF “SPK:1”
SPKR-A ON “SPK:2”
SPKR-B OFF “SPK:3”
SPEAKER
Select
SPKR-B ON “SPK:4”
“SPK:ab”, a=SPK-A,b=SPK-B
“SPK:11”(A-OFF,B-OFF)
“SPK:21”(A-ON,B-OFF)
“SPK:12”(A-OFF,B-ON)
“SPK:22”(A-ON,B-ON)
To Next Page
