Marantz SR7005 Service Manual

9
About the photos used for descriptions in the DISASSEMBLY" section.
• The direction from which the photographs used herein were photographed is indicated at "Direction of photograph: ***"
at the left of the respective photographs.
• Refer to the table below for a description of the direction in which the photos were taken.
• Photographs for which no direction is indicated were taken from above the product.
1. FRONT PANEL ASSY
(1) Remove the screws.
The viewpoint of each photograph
(Photografy direction)
［View from above］
Front side
Direction of photograph: B
Direction of photograph: D
Direction of photograph: C
Direction of photograph: A
CABINET TOP
FRONT PANEL ASSY
→
Proceeding :
View from bottom

Marantz SR7005 Specifications

General

Receiver type	Surround
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	140 W
Power output per channel (20-20KHz@8 Ohm)	125 W
HDMI in	6
Audio (L/R) in	8
Composite video in	1
Digital audio coaxial in	2
Digital audio optical in	3
Component video (YPbPr/YCbCr) in	4
Digital audio coaxial out	0
Speakers connectivity type	Clamp terminals
Multichannel pre out connectivity	RCA
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Wi-Fi	-
Ethernet LAN	Yes
Supported radio bands	FM
Optical drive included	No
Display	LCD
Product color	Gold, Silver
Audio decoders	Dolby Digital, Dolby Digital Plus, Dolby Pro Logic IIz, Dolby TrueHD, DTS, DTS 96/24, DTS-ES
Apple docking compatibility	Not supported
Power consumption (standby)	0.2 W
Power consumption (typical)	750 W

Weight and Dimensions

Depth	406 mm
Width	440 mm
Height	185 mm
Weight	13000 g
