Example connection when using two sets of Dolby Atmos Enabled speakers
.
C
SBL
SBR
SW
SL SR
FL
FR
FDL FDR
SDL SDR
0
Set “Height” - “Dolby Sp” to “4ch” in the menu when connecting in this
configuration. (v
p. 232)
.
FDR FDL
HEIGHT 1
z
FR FL C SR SL
SW
SBR SBL
SDR SDL
HEIGHT 2
z
Power amplifier
z
You can change the combination of the HEIGHT1 and HEIGHT2 channels in the
settings. (v p. 66)
