RS232C Control Spec Page: 10 / 16
SR9300/8300 Document Version [2.00]
Command Character Sample
DISP DISP J1 "@1J1",0x0D
OSD OSD J2 "@1J2",0x0D
MENU (OK) J3 "@1J3",0x0D
MENU
MENU OFF J4 "@1J4",0x0D
CURSOL UP J5 "@1J5",0x0D
CURSOL DOWN J6 "@1J6",0x0D
CURSOL LEFT J7 "@1J7",0x0D
CURSOL
CURSOL RIGHT J8 "@1J8",0x0D
RDS DISP MODE J9 "@1J9",0x0D
RDS
RDS PTY JA "@1JA",0x0D
VOLUME RESET VOL. RESET JB "@1JB",0x0D
RE-EQ RE-EQ JC "@1JC",0x0D
CHANNEL SELECT CH. SEL. JD "@1JD",0x0D
CH. LEVEL UP JE "@1JE",0x0D
CHANNEL LEVEL
CH. LEVEL DOWN JF "@1JF",0x0D
SELECT SELECT JG "@1JG",0x0D
ENTER ENTER JH "@1JH",0x0D
UP>> JI "@1JI",0x0D
UP/DOWN
DOWN<< JK "@1JK”,0x0D
FACTORY MODE into FACTORY MODE K1 "@1K1",0x0D
SERVICE MODE into SERVICE MODE K2 "@1K2”,0x0D
Command Character Sample
MULTI ROOM OFF L0 "@1L0",0x0D
MULTI ROOM
MULTI ROOM ON L1 "@1L1",0x0D
MUTE (Multi Room) MULTI ROOM MUTE L2 "@1L2",0x0D
MULTI VOL. UP M0 "@1M0",0x0D
MULTI VOL. DOWN M1 "@1M1",0x0D
MULTI VOL. UP FAST M2 "@1M2",0x0D
VOLUME
(Multi Room)
MULTI VOL. DOWN FAST
M3 "@1M3",0x0D
SLEEP MODE (Multi Room) MULTI ROOM SLEEP MODE N0 "@1N0",0x0D
MULTI ROOM SPEAKER ON N1 "@1N1",0x0D SPEAKER
(Multi Room)
MULTI ROOM SPEAKER OFF N2 "@1N2",0x0D
MULTI-CHANNEL INPUT ON N3 "@1N3",0x0D
MULTI-CHANNEL INPUT
MULTI-CHANNEL INPUT OFF N4 "@1N4",0x0D
3-4-2. Special Command list
Command Character Sample
ON P0 "@1P0",0x0D
CONNECTION
OFF
P1 "@1P1",0x0D
!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!! The Commands are CONFIDENTIAL ISSUES !!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!
Command Character Sample
SERIAL WRITE
SERIAL NUMBER WRITE MODE
O0
“@０O0XXXXXXXXX”,0x0D
SERIAL EXIT
SERIAL NUMBER WRITE EXIT
O1
“
@０O1”,0x0D
