Marantz ST4000 - Page 14

POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
(VERS. :VERSION, U:U.S.A., F:JAPAN, K:FAR EAST, N:EUROPE)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
(VERS. :VERSION, U:U.S.A., F:JAPAN, K:FAR EAST, N:EUROPE)
CAPACITORS
CF21 4822 242 10853 FILM SFZ450F FF10045290
CF11 4822 242 11039 FILM SFE10.7MS8H-A-T *FF100230R
CF12 4822 242 11039 FILM SFE10.7MS8H-A-T *FF100230R
CG91 4822 124 12129 ELECT 0.1F *EX000030R
CT21 4822 125 11116 TRIM. VARIABLE *CT000110R
C102 nsp CER. 15pF 50V J nsp
C105 nsp CER. 0.01 F 50V Z nsp
C106 nsp CER. 15pF 50V J nsp
C107 nsp CER. 15pF 50V J nsp
C108 nsp CER. 10pF 50V J nsp
C109 nsp CER. 0.01 F 50V Z nsp
C110 nsp CER. 0.1 F 50V Z nsp
C111 nsp CER. 0.1 F 50V Z nsp
C112 nsp ELECT 1 F 50V nsp
C113 nsp CER. 0.01 F 50V Z nsp
C114 nsp ELECT 220 F 16V nsp
C115 nsp ELECT 4.7 F 50V nsp
C116 nsp CER. 33pF 50V J nsp
C117 nsp CER. 390pF 50V K nsp
C118
nsp CER. 100pF 50V K nsp
C121
C123 nsp ELECT 1 F 50V nsp
C201 nsp CER. 0.1 F 50V Z nsp
C202 nsp CER. 15pF 50V J nsp
C203 nsp CER. 470pF 50V K nsp
C204 nsp CER. 0.1 F 50V Z nsp
C205 nsp ELECT 100 F 16V nsp
C206 nsp CER. 0.001 F 50V K nsp
C207 nsp CER. 0.1 F 50V Z nsp
C208 nsp CER. 8.2pF 50V J nsp
C209 nsp CER. 47pF 50V J nsp
C210 nsp ELECT
1
F 50V nsp
C211 nsp ELECT
4.7
F 50V nsp
C212 nsp ELECT
1
F 50V nsp
C213 nsp CER.
0.0047
F 50V M nsp
C214 nsp FILM
0.0015
F 50V J nsp
C215 nsp FILM
0.027
F 50V J nsp
C301 nsp ELECT 10 F 50V nsp
C302 nsp ELECT 220 F 16V nsp
C303 nsp CER. 0.1 F 50V Z nsp
C304 nsp ELECT 0.47 F 50V nsp
C305 nsp ELECT 3.3 F 50V nsp
C306 nsp ELECT 10 F 50V nsp
C307 nsp ELECT 1 F 50V nsp
C308 nsp ELECT 1 F 50V nsp
C309 nsp ELECT 100 F 16V nsp
C310 nsp ELECT 10 F 50V nsp
C311 nsp ELECT 1 F 50V nsp
C312 nsp CER. 100pF 50V K nsp
C313 nsp CER. 470pF 50V K nsp
C315 nsp CER. 560pF 50V K nsp
C316 nsp CER. 560pF 50V K nsp
C317 nsp ELECT 4.7 F 50V nsp
C318 nsp ELECT 4.7 F 50V nsp
C319 nsp ELECT 2.2 F 50V nsp
C320 nsp ELECT 2.2 F 50V nsp
C321 nsp ELECT 10 F 50V nsp
C322 nsp ELECT 10 F 50V nsp
C323 nsp ELECT 4.7 F 50V nsp
C324 nsp ELECT 4.7 F 50V nsp
C325 nsp FILM 0.0015 F 50V J nsp
C326 nsp FILM 0.0015 F 50V J nsp
C501 nsp CER. 0.01 F 50V Z nsp
C502 nsp ELECT 470 F 10V nsp
C503 nsp CER. 33pF 50V J nsp
C504 nsp CER. 33pF 50V J nsp
C505
nsp CER. 100pF 50V K nsp
C508
C510 nsp CER. 0.022 F 50V Z nsp
C511 nsp ELECT 4.7 F 50V nsp
C512 nsp CER. 0.022 F 50V Z nsp
C515 nsp CER. 0.01 F 50V Z nsp
C516 nsp CER. 5.6pF 50V K nsp
C531 nsp CER. 0.022 F 50V Z nsp
C532 nsp CER. 0.022 F 50V Z nsp
C701 nsp CER. 680pF 50V K nsp
C702 nsp CER. 680pF 50V K nsp
C703 4822 124 41334 ELECT 470 F 35V EA47703510
C704 4822 124 41334 ELECT 470 F 35V EA47703510
C705 9965 000 01264 ELECT 2200 F 25V EA22802510
C706 nsp CER. 0.01 F 50V Z nsp
C707 nsp ELECT 330 F 25V nsp
C708 nsp CER. 0.01 F 50V Z nsp
C709 nsp ELECT 100 F 16V nsp
C711 nsp ELECT nsp
C712 nsp CER. 680pF 50V K nsp
C713 nsp CER. 680pF 50V K nsp
C714 nsp ELECT 47 F 50V
47 F 50V
nsp
C715 nsp ELECT 47 F 50V nsp
C716 nsp ELECT 3.3 F 50V nsp
C720 nsp CER. 0.022 F 50V Z nsp
C801 nsp CER. 390pF 50V K nsp
C802 nsp CER. 0.01 F 50V Z nsp
C803 nsp ELECT 100 F 16V nsp
C804 nsp CER. 33pF 50V J nsp
C805 nsp CER. 39pF 50V J nsp
C806 nsp ELECT 10 F 50V nsp
C807 nsp CER. 100pF 50V K nsp
C808 nsp CER. 0.022 F 50V Z nsp
C809 nsp CER. 0.022 F 50V Z nsp
C901 nsp CER. 0.1 F 50V Z nsp
C902 nsp CER. 0.022 F 50V Z nsp
C903 nsp ELECT 100 F 10V nsp
C905 nsp ELECT 1000 F 6.3V nsp
C907 nsp CER. 18pF 50V J nsp
C908 nsp CER. 12pF 50V J nsp
C909 nsp ELECT 22 F 16V nsp
C910 nsp ELECT 10 F 16V nsp
C911 nsp CER. 22pF 50V J nsp
C912 nsp CER. 18pF 50V J nsp
C921 nsp CER. 0.022 F 50V Z nsp
DIODES
D201 9965 000 01250 1SS131M *HD201290R
D203 9965 000 01250 1SS131M *HD201290R
D302 9965 000 01250 1SS131M *HD201290R
D303 9965 000 01250 1SS131M *HD201290R
D501 9965 000 01250 1SS131M *HD201290R
D202 nsp VARICAP SVC342-L-AA *HD400160R
D502 9965 000 01250 1SS131M *HD201290R
D503 9965 000 01250 1SS131M *HD201290R
D701 4822 130 31878 1N4003 HD200010AR
D702 4822 130 31878 1N4003 HD200010AR
D703 4822 130 11131 ZENER 13V 1/2W *HD301430R
D704 4822 130 11132 ZENER 6.2V 1/2W *HD301450R
D711 4822 130 31878 1N4003 HD200010AR
D712 4822 130 31878 1N4003 HD200010AR
D713 9965 000 01260 ZENER 24V UZ24BMT *HD301700R
D714 4822 130 11132 ZENER 6.2V 1/2W *HD301450R
D801 9965 000 01250 1SS131M *HD201290R
D901 9965 000 01250 1SS131M *HD201290R
D902 4822 130 11608 LED SLR342VCF02 *HI100810R
D903 9965 000 01250 1SS131M *HD201290R
