DIAGRAM - BALE TIE OFF/BALE EJECT FOR V-4830 & V-6030
1 OPERATION
FRONT VIEW
SIDE VIEW
WIRE GUIDES
ARROWS ALIGNED
TO SHOW BALE
MADE POSITION
EJECTOR HOOK ON
PLATEN
INSERT WIRE TIES
THROUGH FLOOR
GUIDES
PALLET RECOMMENDED
HOOK POSITION WHILE
BALING
BALE DOOR
BALE DOOR LATCH
FEED GATE
BALE TIE- INSERT AND PUSH
THROUGH PLATEN AND FLOOR
GUIDES. TIE BALE TIES HAND
TIGHT TO ALLOW FOR EXPANSION.
BALE- AFTER
EJECTION
BALE- DURING
EJECTION
EJECTOR
HOOK WHEN
BALE IS
EJECTED
1-16
