Marathon V-4830 - Power Unit Diagrams

2 MAINTENANCE
POWER UNIT FOR 4830, 6030, 4830HD, 6030HD, & 7230HD
TOP
VIEW
DIRECTIONAL CONTROL VALVE
TO BASE END
OF CYLINDER
TO ROD END OF
CYLINDER
RELIEF VALVE
RETURN LINE
SUCTION LINE
PUMP
ELECTRIC MOTOR
RESERVOIR
REAR SIDE
VIEW
HUB COUPLING
PUMP
DRAIN PLUG
CLEANOUT COVER
SUCTION FILTER
SUCTION LINE
SIGHT GAUGE
FILLER\BREATHER CAP
PRESSURE LINE
PRESSURE LINE
2-16
