Marathon V-4830 - Parts List

2 MAINTENANCE
PARTS LIST
2-13
* After SERIAL NUMBER 127390
** After SERIAL NUMBER 97723
EL ECT RI CA L
03-0004 MOTOR, 10 HP, 3 PH
(208,230,460 VAC)
XXXX XXXX
03-0010 LIMIT SWITCH ARM XXXXXXX
03-0012 LIMIT SWITCH, 5 DEG. FREE TRAVEL XXXXXXX
03-0288 TRANSFORMER
(208, 230, 460 VAC)
XXXXXXXXX
03-0335 LIGHT, RED OMNI GLOW XXXXXXXXX
03-0343 MOTOR, 15 HP, 3PH X
03-0398 LEGEND, BALE MADE XXXXXXX
03-0403 SOLENOID COIL FOR 02-0357 XXXXXXXXX
03-0148 MOTOR STARTER, SIZE 2 AB XXXXXXX
03-0486 MOTOR STARTER EXTERNAL RESET XXXXXXXXX
03-0488 FUSE, 1.5 AMP XXXXXXXXX
03-0498 SWITCH, MAGNETIC INTERLOCK XXXXXXXXX
03-0509 LEGEND, AUTOCYCLE, 22mm XXXXXXXXX
03-0510 LEGEND, MANUAL DOWN, 22mm XXXXXXXXX
03-0511 LEGEND, MANUAL UP, 22mm XXXXXXXXX
03-0512 LEGEND, STOP, 22mm XXXXXXXXX
03-0513 LEGEND, OFF/ON, 22mm XXXXXXXXX
03-0600 PRINTED CIRCUIT BOARD XXXXXXXXX
03-0928 SWITCH, BLACK PUSHBUTTON, 22mm XXXXXXXXX
03-0929 PUSHBUTTON, RED MUSHROOM HEAD XXXXXXXXX
03-0934 SWITCH, 2 POS. KEYED SELECTOR XXXXXXXXX
03-0935 KEY, FOR 03-0934 XXXXXXXXX
03-0936 CONTACT 1, N.O. FOR 22mm XXXXXXXXX
03-0937 CONTACT 1, N.C. FOR 22mm XXXXXXXXX
03-0987 SWITCH, GREEN PUHSBUTTON, 22mm XXXXXXXXX
03-1367 ENCLOSURE (PANEL BOX) XXXXXXX
03-1676 MOTOR STARTER, IEC CONTACTOR XX
03-1678 MOTOR STARTER, SOLID STATE XX
03-1679 ENCLOSURE (PANEL BOX) XX
03-1681 MOTOR STARTER, AUX. CONTACT XX
99-6875 DISCONNECT CONVERSION KIT XXXXXXX
HYDRAULIC
02-0050 SUCTION FILTER XXXXXXXXX
02-0197 BREATHER CAP XXXXXXXXX
02-0198 SIGHT GAUGE, 3 INCH XXXXXXXXX
02-0214 RELIEF CARTRIDGE XXXXXXXXX
02-0244 HUB COUPLING XXXXXXXXX
02-0264 SUBPLATE XXXXXXXXX
02-0357 VALVE, DIRECTIONAL CONTROL XXXXXXXXX
02-3839 PUMP, 9 GPM, VANE X X XXXX
02-1013 PUMP, 13 GPM, VANE X X X
04-0260 CYL. 6 BORE, 3 ROD, 48 STROKE XXXXX XX
04-0261 SEAL KIT, F/04-0260 XXXXX XX
04-0500 CYL. 2.5 BORE, 18.5 STROKE X
04-0520 CYL. 7 BORE, 26 STROKE X X
04-0521 SEAL KIT, F/04-0520 XX
MISC. HARDWARE
05-0256 WIRE, BALE TIE XXXXXXXXX
05-0277 SPRING, 3/4 OD X 4 LONG X X X X X X
05-0278 TURNBUCKLE, W/8" HANDWHEEL XXXXXXX
05-0283 CHAIN, 2040 RIVET XXXXXXXXX
05-0285 SPROCKET, F/2040 RIVET CHAIN XXXXXXXXX
05-0664 MASTER LINK, F/2040 RIVET CHAIN XXXXXXXXX
05-2382 CHAIN, F/EJECTOR XX
05-2383 LINK F/EJECTOR CHAIN XX
05-2384 TURNBUCKLE XX
22-4132 FEED GATE STRIKER (BOLT IN) XXXXXXXXX
4830* 6030**4830HD 6030HD
7230HD
6030LP
6042LP
PART # DESCRIPTION
4830
6030
