V-4830 V-6030 V-4830HD V-6030HD V-7230HD V-6030LP V-6042LP
Performance:
Cycle Time:(empty) 69 sec. 69 sec. 69 sec. 69 sec. 48 sec. 48 sec. 48 sec.
Total Force: 62,200 lbs. 62,200 lbs. 62,200 lbs. 62,200 lbs. 70,700 lbs. 80,800 lbs. 80,800 lbs.
Platen Face PSI: 47 PSI 37 PSI 47 PSI 37 PSI 35.3 PSI 48 PSI 34 PSI
Electrical:
Motor: 10 HP 10 HP 10 HP 10 HP 15 HP 10 HP 10 HP
RPM: 1760 RPM 1760 RPM 1760 RPM 1760 RPM 1725 RPM 1760 RPM 1760 RPM
Timer Settings-
T1 75 75 75 75 51 55 55
T2 38 38 38 38 26 28 28
Hydraulic:
Pump: 9 GPM 9 GPM 9 GPM 9 GPM 13 GPM 9 GPM 9 GPM
Pressure:(3 Phase) 2200 PSI 2200 PSI 2200 PSI 2200 PSI 2500 PSI 2100 PSI 2100 PSI
Pressure:(1 Phase) 1700 PSI 1700 PSI 1700 PSI 1700 PSI N/A 1700 PSI 1700 PSI
Cylinder Bore: 6" 6" 6" 6" 6" 7" 7"
Cylinder Rod: 3" 3" 3" 3" 3" 4" 4"
Cylinder Stroke: 48" 48" 48" 48" 48" 26" 26"
Reservoir Capacity: 14 GAL. 14 GAL. 14 GAL. 14 GAL. 14 GAL. 17 GAL. 17 GAL.
Demensional Data:
Feed Opening-
Height: 24" 24" 24" 24" 24" 19" 19"
Width: 48" 60" 48" 60" 72" 60" 60"
Feed Height: 50" 50" 50" 50" 52" 38" 38"
Bale Size-
Width: 48" 60" 48" 60" 72" 60" 60"
Depth: 30" 30" 30" 30" 30" 30" 42"
Height: 48" 48" 48" 48" 48" 30" 30"
Bale Door Clearance 49" 61" 49" 61" 73" 61" 61"
Overall Height: 139" 139" 139" 139" 141" 95" 95"
Overall Width: 68" 80" 68" 80" 92" 93" 93"
Overall Depth: 48 1/4" 48 1/4" 51 1/2" 51 1/2" 51 1/2" 48" 64"
Total Weight: 3,600 lbs. 4,050 lbs. 4,150 lbs. 4,600 lbs. 6,000 lbs. 5,000 lbs. 6,200 lbs.
Bale Ties 14ga. X 14' 14ga. X 14' 14ga. X 14' 14ga. X 14' 14ga. X 14' 14ga. X 11' 14ga. X 11'
2-10
NOTE: The timer settings are determined by the cycle time of the machine which is
based upon the cylinder bore, rod size, stroke, and pump size. T2 is set at the amount
of time it takes the cylinder to fully extend, and T1 is set at the amount of time it takes to
fully extend and fully retract.
See chart for the correct timer settings for your machine.
