Service Manual 1000660 T5 1000661 T10 1000665 PB5 1000666 PB10 Ecoboiler 231109.doc Page 10 of 22
4.3. ACCESS TO INTERNAL COMPONENTS:
To access the tank:
To access the internal components:
Allow to cool. Remove the
outer
lid.
Ensure that the tank is cool,
before removing inner lid. To
remove inner lid, undo 4
butterfly nuts
The tank is now accessible
for
cleaning.
Ball Stud/
Spring Clip
locations
Ball Stud
Spring
Clip
