Marcy 1201U - Assembly Instructions; Step 1: Attach Stabilizers; Step 2: Connect Wires and Front Post

www.puretecfitness.com
6
STEP 1
ASSEMBLY INSTRUCTION
Attach the front stabilizer (2) to the main frame (1), Secure using two curved washer (16),
two Spring Washer (13) and Allen Bolt (15).
Attach the rear stabilizer (3) to the main frame (1), Secure using two curved washer (16),
two Spring Washer (13) and Allen Bolt (15).
STEP 2
15
16
13
2
1
16
3
13
15
Connect the middle computer wire (33) with lower computer wire (34).
Turn the tension knob (60) to level 8 and connect the tension knob w/upper tension cable
(60) to the extension with the lower tension cable (61).
Insert the front post (04) into the main frame (1) and secure using four allen screws (18)
and four curved washers (16).
33
60
60
33
4
34
61
33
18
61
34
16
16
18
1
