13.0 Options manual: ST210 VibeSpike-Aerator
The MAREDO ST210 VibeSpike-Aerator is a vibratory spike aerator. The vibration
of the spikes breakes compaction.
13.1 First start: After connecting the ST210 to the STrac 700 (See 5.2 ST head
connection Working depth can be adjusted by the two quick adjusters on the front
roller. Actual adjusted working depth can be checked by reading the depth
indicator decals on the front of the ST head. Working depth can be increased
gently until the desired result is accomplished.
13.2 Lock ST head: The ST210 can be locked in two ways:
13.2.1 Lock left to
right rotation pivoting
around the central
connection pin:
Locking bolt in position A
= fixed position.
Locking bolt in position B
= flexible position, ST
head can pivot around
central connection pin.
13.2.2 Limit forward
to backwards pivoting:
Option A: 2 x pushrods for optimal flexibility.
Option B: 1 x locking strip for reducing
flexibility.
13.3 Check V-belt drive: After the
first 8 working hours the side V-belt
drive needs to be checked and re-
adjusted if needed. After that, every
100 hours the belt tension needs to be
checked.
To tension the V-belts first loosen the
two nuts ‘A’ on the inside of the PTO
cover. Next use tensioner ‘B’ on the
underside to tension the V-belt by
moving the whole top pulley tensioning assembly upwards. Tension till the belts
can be pushed in 5 mm/ 0.2”. Do not over tension the belts as it may
seriously damage the drive line.
13.4 Maintenance: Clean and check for broken or loose parts. Only use original
MAREDO spare parts. Always clean with low pressure water or compressed air.
Never use a high-pressure washer.
