5.0 First start and first use
After first unpacking (See Separate MAREDO ST unpacking manual) it is important
to first check the STrac 700 before starting it for the first time:
5.1 First checks and engine start
5.1.1 Check if all protection covers are in place and undamaged.
5.1.2 Check if the engine oil level is correct. This can be checked by pulling out
the grey oil level stick which is located on the front of the HONDA engine (see fig.
1). Oil level should be between the marks.
5.1.3 Check if the hydraulic oil level is correct. This can be checked by pulling out
the oil level stick in the hydraulic tank. Make sure the STrac 700 stands on a flat
and level surface. This dipstick is easy to reach through the hole in the top cover.
The oil level should be between the bottom and top mark. NEVER START THE
ENGINE WHEN THE OIL LEVEL IS TOO HIGH OR TOO LOW. Drain oil when the oil
level is too high or fill with extra oil when the level is too low. See 2.0 Technical
specifications for the correct oil.
5.1.4 Check if the PTO lever is in the top position: O (see fig. 2) PTO OFF
5.1.5 Take all needed safety precautions before and during filling the gasoline
tank. Make sure not to spill gasoline over the engine. In case gasoline is spilled
over or beside the engine, the engine may not be started for 20 minutes.
Place the tank cap back right after fuelling.
5.1.6 Check and open the fuel valve on the engine (see fig 1.)
5.1.7 Put the motor switch to ‘ON’ (see fig 1.) and check if the Emergency Stop
on the handlebar is in its top position: ON
5.1.8 For a first (cold) start put the Choke lever on ‘Choke’ and Throttle on 40 –
50%
5.1.9 Pull engine cord gently towards you. Make sure not pull too hard to prevent
injuries. The engine should now start within 1 – 2 pulls. For a Cold start leave the
Choke on for about 10 seconds and then switch the Choke off. The Engine should
now run smooth. (In case it does not please see 7.0 Trouble shooting). Give the
engine some time to warm up.
