10
www.markilux.com
1.4.3 Track-only xture
0
+
0$ %$
37
105
208
116
70
60
210
H
187
84
21
min. 100
max. 1000
30
50 MA
BA
76046.
76046.
M
S A-A
A
A
min. 300
max. 400
Overview of dimensions markilux 8800 / 8800 tracx
Fixture type 32
M = overall awning width
H = projection
FW = width between xing points
MA = xture width = awning width between xture points
S = cross section
1 = track bracket with adjustable head
2 = track bracket with adjustable head
3 = from a xture width (MA) of 601 cm an cassette support assembly,
76183., is required
4 = from a xture width (MA) of 451 cm an additional cassette/casing
support is required
5 = cover support tube (the required quantity can be found in the size
grid in our sales documentation)
6 = from a xture width of (MA) 451 cm an additional support bracket (or
adjustable support bracket) for awnings with cover support tube is
required
76046. = track bracket assembly with adjustable head, height 100 mm
measurements in mm
