1.4.2 Face xture
0
+
0$ %$
37
116 60
70
105
H
210
187
16
204
84
AX
MA
30
50
BA
min. 100
max. 1000
A
A
S A-A
76063.
76064.
(76181.)
76046.
M
W
WAX
5° 26
10° 32
15° 37
20° 43
25° 47
30° 50
35° 52
40° 53
45° 53
Overview of dimensions markilux 8800 / 8800 tracx
Fixture type 12
M = overall awning width
H = projection
FW = width between xing points
MA = xture width = awning width between xture points
W = pitch
AX = distance cassette - wall
S = cross section
1 = face xture cassette bracket
2 = track bracket with adjustable head
3 = from an extension (H) of 401 cm an additional track bracket (for
xture types 22, 41, 51) is required
4 = from a xture width (MA) of 451 cm an additional cassette coupling
bracket is required
5 = cover support tube (the required quantity can be found in the size
grid in our sales documentation)
76063. = face xture cassette bracket assembly, pitch adjustable from 5°to
45°,left
76064. = face xture bracket assembly, pitch adjustable from 5°to 45°, right
76181. = coupling cassette bracket assembly, face xture, pitch adjustable
from 5°to 45°
76046. = track bracket assembly with adjustable head, height 100 mm
measurements in mm
