Markilux 8800 User Manual

6
www.markilux.com
Face xture bracket assembly,
pitch adjustment range
5 to 45°
Face xture bracket assembly,
pitch adjustment range
5 to 45°
Cassette coupling bracket
assembly, face xture bracket,
pitch adjustment range
5 to 45°
left right
face xture
76063. 76064. 76181.
40
126
Bottom xture bracket
assembly
for mounting onto a frame
40
126
Bottom xture bracket assem-
bly for mounting onto a frame
Cassette coupling bracket
assembly for mounting onto
a frame
left right for coupling point
76061. 76062. 76180.
235—535
Raised cassette xture bracket
assembly
foot can be moved up to 45°
backwards, head of cassette
xture bracket can be tilted
forwards up to 45°
235—535
Raised cassette xture bracket
assembly
foot can be moved up to 45°
backwards, head of cassette
xture bracket can be tilted
forwards up to 45°
235—535
Raised cassette xture bracket
assembly
foot can be moved up to 45°
backwards, head of cassette
xture bracket can be tilted
forwards up to 45°
left, for mounting onto frame right, for mounting onto frame coupling point for mounting
onto frame
76067. 76068. 76198.
38
132
100
Cassette support assembly
for mounting onto frame
140
132
38
Cassette support assembly for
mounting onto frame
Cassette coupling bracket
assembly for track xture, rigid
Höhe 100 mm height 140 mm Fixture type 31 and 32
76183. 76184. 76069.
Accessories
Storm safety bracket assembly
for the cassette (recommen-
ded in windy locations and as
an additional safety measure
for the cassette)
29
20
34
Diagonal tensioning kit
(2 wire tensioners, 1 support
wire)
270
60
Bracket assembly for light/
wind/rain sensor
76197. 71790. 76050.
wall sealing prole
30
44
40
Angle bracket to prevent
deection of the cover support
tube for bracket height 100
mm
131- 381
Support assembly to prevent
deection of the cover support
tube, can be shortened to
between 70 and 320 mm
(with clamp plate)
available by the metre
assembly example: see face
xture with wall sealing prole
for assembly example refer
to section "Installation dimen-
sions"
for assembly example
Installation dimensions
77780. 76065. 71780.
bracket assembly for cover
support tube
coupling bracket assembly for
cover support tube
Storm security device assem-
bly / track slider
76019. 76059. 76235.
108
Bottom xture assembly right
reveal 76076
and
left 76077.
76076. + 76077.
1.3 Mounting brackets
Cassette xture brackets
