21
CV Meaning Value Comment
130 POM Switching Function Turnout 4, red 0 – 18 Switches the “red“ output for the fourth turnout
131 POM Pulse Width 0 – 255 255 = 100 %
132 POM Period 0 – 255 Time interval between the pauses; 1 = 0.05 sec.
133 POM Switching Function Turnout 4, green 0 – 18 Switches the “green“ output for the fourth turnout
134 POM Pulse Width 0 – 255 255 = 100 %
135 POM Period 0 – 255 Time interval between the pauses; 1 = 0.05 sec.
We recommend the following pulse widths und periods for our turnout mechanisms:
C Track turnout: 30%, 250 milliseconds
K Track turnout: 75%, 500 milliseconds
M Track turnout: 75%, 1000 milliseconds
Automatic Turnout Circuits (CV 34 & CV 35)
Value Name Comment
0 2 turnouts Two outputs, one for each turnout, are switched in turn
1 Three-way turnout 4 outputs are linked together for a three-way turnout with 2 mechanisms
2 Double slip switch 4 outputs are linked together for a double slip switch with 2 mechanisms
