20
Configuration of the Outputs
(For switching functions, see page 22)
CV Meaning Value Comment
112 POM Switching Function Turnout 1, red 0 – 18 Switches the “red“ output for the first turnout
113 POM Pulse Width 0 – 255 255 = 100 %
114 POM Period 0 – 255 Time interval between the pauses; 1 = 0.05 sec.
115 POM Switching Function Turnout 1, green 0 – 18 Switches the “green“ output for the first turnout
116 POM Pulse Width 0 – 255 255 = 100 %
117 POM Period 0 – 255 Time interval between the pauses; 1 = 0.05 sec.
118 POM Switching Function Turnout 2, red 0 – 18 Switches the “red“ output for the second turnout
119 POM Pulse Width 0 – 255 255 = 100 %
120 POM Period 0 – 255 Time interval between the pauses; 1 = 0.05 sec.
121 POM Switching Function Turnout 2, green 0 – 18 Switches the “green“ output for the second turnout
122 POM Pulse Width 0 – 255 255 = 100 %
123 POM Period 0 – 255 Time interval between the pauses; 1 = 0.05 sec.
124 POM Switching Function Turnout 3, red 0 – 18 Switches the “red“ output for the third turnout
125 POM Pulse Width 0 – 255 255 = 100 %
126 POM Period 0 – 255 Time interval between the pauses; 1 = 0.05 sec.
127 POM Switching Function Turnout 3, green 0 – 18 Switches the “green“ output for the third turnout
128 POM Pulse Width 0 – 255 255 = 100 %
129 POM Period 0 – 255 Time interval between the pauses; 1 = 0.05 sec.
