22
Contents as Delivered
1 decoder
1 Circuit board with a 21-pin connector
1 NEM 8-pole connector
1 Circuit board retainer (only 60942)
1 Screw (only 60942)
1 Adhesive pad (only 60962)
Installation instructions
Warranty card
Tools also needed for the installation procedure include:
regular and cross-point screwdrivers, tweezers, and solder-
ing station with a maximum soldering temperature of up to
30 watts / 300˚Celsius / 572˚Fahrenheit with a fi ne tip, solder-
ing ux for electronics (0.5 - 1 mm / 0.02” – 0.04” diameter),
de-soldering braid or a de-soldering pump.
Safety Notes
•
WARNING! Sharp edges and points required for operation.
• Do wiring and assembly work only on a voltage-free
or grounded work mat. Failure to do this can lead to
dangerous static charge from your body and to damage
to the components.
• Operate the decoder only with the authorized voltage
(see technical data).
There is a danger of burning yourself when working
with a soldering station.
Using the Product as Intended
The 60942/60969 decoders are for converting Märklin/Trix H0
locomotives to digital.
! Not suitable for motors with fi eld-wound coils. Locomoti-
ves with these motors must be converted with the appropri-
ate motor retrofi t kits, item numbers 60941 60943 or 60964.
! Important: The following locomotives (locomotive-specifi c
decoder) cannot be converted with this decoder.
Items:
26410
26453
26490
26557
26561
26562
29094 (only E 94)
29440 (only E 10)
29500 (only E 50)
37010
37011
37044
37226
37227
37239
37274
37275
37321
37346
37403
37404
37435
37485
37501
37504
37505
37530
37542
37573
37574
37575
37580
37581
37607
37733
37734
37777
37786
37787
37790
37791
37867
37940
37941
37993
39014
39022
39051
39081
39110
39123
39140
39185
39303
39340
39343
39390
39392
39393
39399
39404
39441
39563
39564
39565
39643
39836
39837
39838
39896
39972
39986
