marklin 60942 - CV Table for DCC

34
CV
Explanation Values Default Notes
1 Main address 1 - 127
3
Short address 1 - 127
If CV 29 / Bit 5 = 0
2
PoM
Minimum speed (Vmin) 0 - 255
5
Value must be lower than Vmax, CV 5.
(see CV 67)
3
PoM
Acceleration delay (AV) 0 - 255
25
CV value multiplied by 0.9 gives the time
from being stopped to maximum speed.
4
PoM
Braking delay (BV) 0 - 255
16
CV value multiplied by 0.9 gives the time
from maximum speed to being stopped.
5
PoM
Maximum speed (Vmax) 0 - 255
255
Speed at the highest speed level.
Value must be higher than Vmin, CV 2.
(see also CV 94)
7 Manufacturer’s version number (software version)
–
Read only
8
Manufacturer identification / ID
Decoder reset (default or factory setting)
–
8
131
–
Read only
Value cannot be read
13
PoM
Functions F1 - F8 with an alternative track signal 0 - 255
0
altern. track signal = MM, analog
0 = func. # off, 1 = Func. # on
[ F8 F7 F6 F5 F4 F3 F2 F1 ]
14
PoM
Functions FL, F9 - F15 with an alternative track signal 0 - 255
1
altern. track signal = MM, analog
0 = func. / off, 1 = Func. / on
[ F15 F14 F13 F12 F11 F10 F9 FL ]
17 Expanded address, higher value byte 192 - 231
192
Long address 1 - 10239 (128)
If CV 29 / Bit 5 = 1
18 Expanded address, lower value byte 0 - 255
128
CV Table for DCC
PoM (“Programming on Main”) must be supported by the locomotive controller / central controller.
