marklin 60942 - Page 33

33
CV
Explanation Values Default Notes
73
Storing different states: (misc. persistence)
Bit 0: storing function states
Bit 1: storing speed
Bit 2: starting up with/without ABV after a reset
0 - 7
0 / 1
0 / 2
0 / 4
7
0 = do not store / 1 = store
0 = do not store / 2 = store
0 = without ABV / 4 = with ABV
74
Storing different states: (misc. preserve)
Bit 0: storing direction of travel
0 - 1
1 0 = do not store / 1 = store
75
Address 2 (1st consecutive address)
1 - 80
60949=25
60948=73
Address can be activated/deactivated
subject to CV 49.
76
Analog DC startup voltage
1 - 63 {x4}
100
Note for CS1: (140)
The CS1 shows this value inverted.
77
Analog DC maximum speed
1 - 63 {x4}
60949=215
60948=230
78
Analog AC startup voltage
1 - 63 {x4}
100
Note for CS1: (140)
The CS1 shows this value inverted.
79
Analog AC maximum speed
1 - 63 {x4}
60949=215
60948=230
CV Table for fx (MM)
* () = 6021 Control Unit {} = the values entered are multiplied times “x” (factor).
