30
CV
Explanation Values Default Notes
1
Address 1 (main address) 1-255 (1 - 80)* 78
Address is always active and is not subject
to CV 49.
2
Minimum speed (Vmin) 1-255 (1 - 80)* 5
Speed at the smallest speed level. Value
must be smaller than Vmax, CV 5.
3
Acceleration delay (AV)
1-255 (1 - 80)*
[0,00s - 20,00sec.]
25
CV value multiplied by 0.25 gives the time
from complete stop to maximum speed.
4
Braking delay (BV)
1-255 (1 - 80)*
[0,00s - 20,00s]
16
CV value multiplied by 0.25 gives the time
from the maximum speed to absolute stop
5
Maximum speed (Vmax)
1-255 (1 - 63)*
{x4}
255
Speed at the highest speed level. Value
must be greater than CV 2.
8
Decoder reset (default or factory setting) 8 - Value is not written.
17
Address 3 (2nd consecutive address) 1-255 (1 - 80)* 254
Address can be deactivated/activated
subject to CV 49.
18
Address 4 (3rd consecutive address) 1-255 (1 - 80)* 253
Address can be deactivated/activated
subject to CV 49.
CV Table for fx (MM)
* () = 6021 Control Unit {} = the values entered are multiplied times “x” (factor).
Decoder functions and CV settings
The following pages have the functions and the CVs
presented in tabular form. These CVs can be given a number
of settings and can be assigned to a number of function
buttons.
You‘ll find the CVs and their applications for the track
formats fx (MM) and DCC in separate tables.
The track format mfx can be easily set by using the
display on the CS 2 with Software Version 2.0 and higher.
You or your dealer may have to install an update on your
60213/60214/60215 Central Station.
