CV Table for fx (MM)
Decoder functions and CV settings
The following pages have the functions and the CVs presented in
tabular form. These CVs can be given a number of settings and
can be assigned to a number of function buttons.
You‘ll nd the CVs and their applications for the track formats fx
(MM) and DCC in separate tables.
The track format mfx can be easily set by using the display
on the CS 2 with Software Version 2.0 and higher. You or your
dealer may have to install an update on your 60213/60214/60215
Central Station.
CV
Explanation Values Default Notes
1
Address 1 (main address) 1-255 (1 - 80)*
78
Address is always active and is not subject
to CV 49..
2
Minimum speed (Vmin) 1-255 (1 - 80)*
4
Speed at the smallest speed level. Value
must be smaller than Vmax, CV 5.
3
Acceleration delay (AV) 1-255 (1 - 80)*
12
CV value multiplied by 0.25 gives the time
from complete stop to maximum speed.
4
Braking delay (BV) 1-255 (1 - 80)*
12
CV value multiplied by 0.25 gives the time
from Maximum speed to complete stop.
5
Maximum speed (Vmax)
1-255 (1 - 63)*
{x4}*
180
Speed at the highest speed level. Value must
be greater than CV 2.
7
Automatic Calibration
77
Enter Value 77. Value 77 is not stored
continuously.
8
Decoder reset (default or factory setting) 8 Value is not written.
17
Address 3 (2nd consecutive address) 1-255 (1 - 80)*
254
Address can be deactivated/activated
subject to CV 49.
18
Address 4 (3rd consecutive address) 1-255 (1 - 80)*
253
Address can be deactivated/activated
subject to CV 49.
* () = 6021 Control Unit {} = the values entered are multiplied times “x” (factor).
