marklin 60972 - CV Table for DCC

34
CV Table for DCC
PoM (“Programming on Main”) must be supported by the locomotive controller / central controller.
1
An extensive table for function mapping can be found on the Internet at: http://www.maerklin.de/de/service/
technische-informationen
CV
Explanation Values Default Notes
1 Main address 1 - 127
3
Short address 1 - 127
If CV 29 / Bit 5 = 0
2
PoM
Minimum speed (Vmin) 0 - 255
4
Value must be lower than Wert muss
Vmax, CV 5. (see CV 67)
3
PoM
Acceleration delay (AV) 0 - 255
12
CV value multiplied by 0.9 gives the time
from being stopped to maximum speed.
4
PoM
Braking delay (BV) 0 - 255
12
CV value multiplied by 0.9 gives the time
from maximum speed to being stopped.
5
PoM
Maximum speed (Vmax) 0 - 255
180
Speed at the highest speed level.
Value must be higher than Vmin, CV 2.(see
also CV 94)
7
Automatic Calibration
Hersteller Versionsnummer (Softwareversion)
Enter Value 77. Value 77 is not stored
continuously.
8
Manufacturer identication / ID
Decoder reset (default or factory setting)
–
8
131
Read only
Value cannot be read
13
PoM
Functions F1 - F8 with an alternative track signal 0 - 255
1
0 = Func. MM or analog off
1 = Func. MM or analog on
[ F8 F7 F6 F5 F4 F3 F2 F1 ]
14
PoM
Functions FL, F9 - F15 with an alternative track signal 0 - 255
1
0 = Func. MM or analog off
1 = Func. MM or analog on
[ F15 F14 F13 F12 F11 F10 F9 FL ]
17 Expanded address, higher value byte 192 - 231
192
Long address 1 - 10239 (128)
If CV 29 / Bit 5 = 1
18 Expanded address, lower value byte 0 - 255
128
