CV Table for DCC
PoM must be supported by the locomotive controller / central controller.
CV
Explanation
Values
Default Notes
66
PoM
Forward trim 0 - 255
128
The CV value divided by 128 gives the fac-
tor with the speed level is multiplied when
the locomotive is running forward.
67
PoM
-
94
PoM
Speed table speed level 1 (Vmin) to
speed table speed level 28 (Vmax)
0 - 255
95
PoM
Reverse trim 0 - 255
128
The CV value divided by 128 gives the fac-
tor with the speed level is multiplied when
the locomotive is running in reverse.
145
PoM
Switching range 0 - 128
128
128 = 50% of speed level, 64 = 25% of
speed level
173
PoM
Storing different states:
Bit 0: Storing function states
Bit 1: Storing speed
Bit 2: After a reset starting up with/without ABV
Bit 3 - 7: always 0
0 / 1
0 / 2
0 / 4
7
0 = do not store, value = store
Individual values must be added.
174
PoM
Storing different states:
Bit 0: Storing direction of travel
Bit 1 - 7: always 0
0 / 1
1
0 = do not store
1 = store
176
PoM
Vmin Analog DC 0 - 255
50
Must be smaller than CV 177
177
PoM
Vmax Analog DC 0 - 255
170
Must be larger than CV 176
178
PoM
Vmin Analog AC 0 - 255
60
Must be smaller than CV 179
179
PoM
Vmax Analog AC 0 - 255
190
Must be larger than CV 178
