Marmitek Connect TS21 User Manual

© MARMITEK
6
6.2 Left
1. Optical In: Connect your
audio sources to these inputs
with an optical (Toslink) digital
audio cable (not supplied).
6.3 Right
1. Optical Out: Connect your
audio amplifier or powered
speakers to this output using
an optical (Toslink) digital
audio cable (not supplied).
6.4 Back
1. DC 5V: Connect the power
adapter (included) and plug it
into the mains.
2. Input: Use this button to
select which audio input is
switched to the audio output.
7 Connection diagram
AIN B
1
OPTIC ALOUT
1
DC 5V
A B
1

Marmitek Connect TS21 Specifications

General

Brand	Marmitek
Model	Connect TS21
Category	Switch
Language	English
