Service Manual - DVH 09/12/18/24 SF Series
Service Manual - DVH 09/12/18/24 SF Series
63
65
2 Electrical
parts
How to remove the electrical
parts.
1) Remove the front
panel from procedure 1.
2) Pull out the room temp.
sensor (T1). Remove the two
screws for the ground
connection.
3) Remove the fixing screw.
4) Pull out the coil temp.
sensor.
5) From the side direction,
open the electronic control box
cover fixing by clips. Pull out
the fan motor connector and
swing motor connector. Then
remove the electronic control
box.
②
③
④
⑤
