Mars DVH Series User Manual

Service Manual - DVH 09/12/18/24 SF Series
Service Manual - DVH 09/12/18/24 SF Series
67
69
2
Fan assembly
How to remove the fan
assembly.
1) After removing the
panel plate following
procedure 1.
2) Remove the nut fixing
the fan, and remove the
fan.
3) After removing the top
cover, unfix the hooks and
then open the electronic
control box cover.
○
2
○
3
compressor
T3,T4,T5 sensor
Motor
Electronic expansion valve
4 way valve
