Service Manual - DVH 09/12/18/24 SF Series
Service Manual - DVH 09/12/18/24 SF Series
68
70
4) Disconnect the
connector for fan motor
from the electronic control
board.
5) Remove the four fixing
screws of the fan motor,
then remove the motor.
○
5
④
