Service Manual - DVH 09/12/18/24 SF Series
Service Manual - DVH 09/12/18/24 SF Series
69
71
3 Electrical
parts
How to remove the
electrical parts.
1) After finishing item 1
and item 2, remove the
connector for the
compressor .
2) Pull out the two blue
wires connected with the
four way valve.
3) Pull out connectors of
the condenser coil temp.
sensor (T3), outdoor
ambient temp. sensor (T4)
and discharge temp.
sensor (TP).
○
1
○
2
○
3
