OVERVIEW
This User’s Manual provides step-by-step procedures for performing either single or dual-tasking PatrionPlus system
functions. For further details, refer to your PatrionPlus Technical Manual.
CHANGE LANGUAGE
Available screen display languages: German, English, Spanish, French, Italian, Portuguese, Finnish, Swedish.
To change language, begin from homescreen. Press . Highlight Language option; press . Highlight
desired language; press . Note: Only screen prompts convert; entered messages stay in original language.
SET UP FUNCTIONS
PRINTHEADS
To perform printhead setup functions:
• Always begin from the homescreen.
• Dual-Tasking only: Press either or to select correct task number.
• Press . Highlight Printheads option and press . Printhead Setup screen
is displayed.
1. Use to highlight printhead you want to configure.
2. Use to select printhead size.
3. Use to set print direction and move highlighted printheads to the desired
printline positions.
4. Type offset value from 0 to 99; press .
5. Either type dot size (from 1 to 9 for VJ printheads or 1 to 4 for HR printheads) or
keep default (2); press .
6. Type aspect ratio value from 0 to 9; press .
