ENGLISH-12
29933/02080 Rev CA
UTILITY FUNCTIONS
To access the Utility functions, always begin from the homescreen. Press .
Highlight desired option; press . The applicable screen/function is active.
LOGOFF/LOGON
Highlight Logoff; press . The system is logged off.
Press , type the correct password, and press or .
PURGE PRINTHEADS/PRINT TEST PATTERN
Note: HR printheads cannot be purged electronically. If you only have HR printheads and you try to purge
electronically, your will get an error message that says, “No printheads have been detected.” If you have VJ (Valve
Jet) and HR printheads, only the VJ printheads will appear on the purge screen.
1. Highlight Purge; press .
2. Use to highlight the printhead to be purged.
3. Press or to display the nozzle associated with the highlighted
printhead. If needed, highlight and add more printheads.
4. If you want to purge only one valve, press .
5. Place container in front of printhead nozzle.
6. Press .
7. Block photocell.
8. To stop purging, press or unblock the photocell.
Logging Off
Logging On
Purging a Printhead
