4.3.6 Camera Settings
No. Item. Function Descriptions
1 Zoom ratio Adjust the zoom-in or zoom-out ratio via scroll bar
2 Exposure
• Mode: Select exposure mode (Automatic/Shutter Priority/Aperture Priority/Manual )
• Exposure Comp. Level: Select exposure compensation level
• Gain: The gain limit is adjustable when the exposure mode is set to “Manual”
• Iris: The size of aperture is adjustable when the exposure mode is set to “Manual” or
“Aperture Priority”
• WDR: Set the level of wide dynamic range (WDR) in order to obtain better images in
dynamic lighting environments.
• Shutter Speed: The shutter speed is adjustable when the exposure mode is set to
“Manual” or “Shutter Priority”
3 White balance
• Mode: Select the color temperature mode
• Auto
• Indoor
• Outdoor
• One Push WB
• ATW
• Manual
• Sodium Lamp
• Open Push Trigger: One push color temperature is adjustable when the white
balance mode is set to “One Push Trigger”
• Manual Red/Blue: Manually adjust blue/red color temperature
4 Focus
• Mode: Select manual/automatic focus
• Focus Range: The focusing range is adjustable when the focus mode is set to
“Manual”
• AF Sensitivity: Set automatic focus sensitivity
• AF Frame: Set automatic focus range
5 MIRROR
• Mirror: Set automatic flip mode
1
2 3 4 5
