016.
NOTE: THE FRONT OF THE SPEAKER IS NOT REMOVABLE.
THIS ILLUSTRATION INTENDS TO SHOW THE INTERNAL
SPEAKER LAYOUT. DO NOT ATTEMPT TO REMOVE THE
FRET FOR RISK OF DAMAGING YOUR SPEAKER.
TECHNICAL INFORMATION
ACOUSTIC SPECIFICATION
• PORTABLE STEREO LOUDSPEAKER WITH BASS REFLEX SYSTEM
• DIGITAL CLASS D AMPLIFIERS:1 X 40 W + 2 X 15 W + 1 X 10 W
• 16 mm DOME TWEETER: 1 X
• 2" FULL RANGE DRIVERS: 2 X
• 5.25" WOOFER: 1X
• BASS AND TREBLE TONE CONTROLS
• FREQUENCY RESPONSE: 40–20,000 Hz ±6 dB
• MAXIMUM SOUND PRESSURE LEVEL: 102 dB SPL @ 1 m
CONNECTIVITY
• BLUETOOTH
®
: Bluetooth 5.0 with Qualcomm aptX™
• AUX: 3.5 mm stereo jack
TECHNICAL INFORMATION
• MAINS INPUT VOLTAGE: 100–240 VAC
• MAINS FREQUENCY: 50–60 Hz
• SIZE: 229 X 163 X 350 mm
• WEIGHT: 4.9 kg
BATTERY
• BATTERY TYPE: Built-in, rechargeable Li-ion battery
• PLAYTIME: 20+ h
• CHARGING TIME: 2.5 h
