Marshall Electronics CV630-IP User Manual

English - 24
5. ATW
6. Manual
7. Sodium Lamp
3. 5800k
4. 1700k ~ 10000k
5. 1700k ~ 10000k
6. Custom
7. 2800k
One Push
Trigger
ENTER One push trigger
Manual Red 0 ~ C ~ 128
Adjustable when the white
balance mode is set to
Manual
Manual Blue 0 ~ C ~ 128
Adjustable when the white
balance mode is set to
Manual
Picture effect
1. Off
2. Neg
3. B & W
Sharpness 0 ~ A ~ 14
2D NR
1. Off
2. 1
3. 2
4. 3
3D NR
1. Off
2. Low
3. Typ
4. Max
Image Mode
1. Default
2. Custom
The user may customize
his/her desired image mode
Image Mode
Load
ENTER
Adjustable when the Image
mode is set to Custom.
After selected, the
corresponding Image mode
parameters will be read and
applied to
Custom
Brightness 0 ~ A ~ 15
Adjustable when the Image
mode
is set to
Custom
Hue 0 ~ A ~ 15
Adjustable when the Image
mode is set to Custom
Saturation 0 ~ A ~ 15
Adjustable when the Image
mode is set to Custom
Gamma 0 ~ A ~ 3
Adjustable when the Image
mode is set to Custom
Pan Tilt
Zoom
Pan/Tilt Limit On / Off
Turn on/off the angle limit
setting
Pan Right Limit 0 ~ 170 Limit the right angle
Pan Left Limit -170 ~ 0 Limit the left angle
Tilt UP Limit 0 ~ 90 Limit the upward angle

Marshall Electronics CV630-IP Specifications

General

Megapixel	8 MP
Camera type	Single camera
Sensor type	-
Optical zoom	30 x
Zoom capability	Yes
Optical sensor size	1/2.5 \
Vertical field of view (wide)	70 °
Networking standards	IEEE 802.3at
Maximum frame rate	- fps
Supported video modes	720p, 1080p, 3840p
Video formats supported	H.264, H.265, HEVC
Maximum video resolution	3840 x 2160 pixels
Supported graphics resolutions	1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 3840 x 2160
Pan range	0 - 340 °
Product color	Black
Tilt angle range	0 - 120 °
