English - 26
right keys or the numeric
keys.
Gateway 192.168.100.254
Press [ENTER] to be in
modify mode; select the item
to be modified using the up
and down keys, and modify
the value using the left and
right keys or the numeric
keys.
Audio
Audio In Line In/Mic In Set Audio In
Audio Enable On / Off Turn on/off audio output
Audio Volume 0 ~ A ~ 10 Volume Setting
Encode
Sample Rate
1. 48 KHz (AAC)
2. 44.1 KHz (AAC)
3. 16 KHz (G.711)
4. 8 KHz (G.711)
Set the encode type and
sample rate
SDI supports the audio
output of 48 KHz only
System
Prompt On / Off
Turn on/off the prompt
information on the display
IR Receive On / Off
Tally Lamp Enable / Disable
Language English / Chinese
Initial Position
Last MEM / 1st
Preset
Set the camera lens to
return to the last operated
position or the first preset
position after POWER ON
Control Device
Encoder /
Controller
Control Device setting,
Controller: for joystick
Encoder: for tracking system
Motionless
Preset
On / Off
When the function is
enabled, the screen will
Freeze when Preset is
executed. Freeze will be
released after Preset is
completed.
Control Port RS-232/RS-422
Choose whether the control
interface used is RS-232 or
RS-422
Protocol VISCA/Pelco D
Baud Rate 9600/38400
Choose the transmission
speed of the control signal
VISCA Address 0 ~ 7
Pelco D
Address
1 ~ 255
The Protocol set to Pelco D
allows the camera ID
address to be assigned
To Next Page
