Marshall Electronics
V-LCD70W-SH Operation Manual
PANEL
Screen Size 7” Diagonal
Aspect Ratio 16:10
Resolution 1920 x 1200
Viewing Angle (h x v) 170° x 170° (H/V)
Brightness 450 cd/m
2
Contrast Ratio 1000:1
VIDEO INPUT / OUTPUT*
3G-HD-SDI Input / Output 2 x BNC Female (75 Ω)
HDMI Input / Output 2 x HDMI Female
CONNECTORS
HDMI Video Input
HDMI Video Output
3G-HD-SDI Video Input
3G-HD-SDI Video Output
Tally Hardware Interface HD-15 Female
Stereo Headphone Jack 1/8” (3.5mm) Female Jack
Power Input DC Connector
ELECTRICAL
Power Consumption 1.1A @ 12VDC (13 W)
Voltage Requirement 12 VDC (7 – 15VDC)
MECHANICAL
Weight 1.20 lbs
Operating Temperature -4°F ~ 140°F (-20°C ~ 60°C)
Storage Temperature -22°F ~ 158°F (-30°C ~ 70°C)
DIMENSIONS (H x W x D) 125mm x 196mm x 28.2mm / 4.9” x 7.7” x 1.11”
6. Specifications
TALLY HARDWARE INTERFACE (HD-15)
Activation requires contact closure of pin to ground on the HD-15 connector:
Pin No. Signal
1 Green
2 Red
3 Yellow
4 Ground
5 NC
6 N/C
7 N/C
8 N/C
9 N/C
10 N/C
11
N/C
12
N/C
13
N/C
14
N/C
15
N/C
* Maximum 1 loop out for the best result
