Marshall Electronics V-LCD70W-SH User Manual

3
www.LCDracks.com
Marshall Electronics
1. Installation & Initial Setup
Unpacking
Carefully unpack the V-LCD70W-SH monitor and verify that the following items are included:
• V-LCD70W-SH Monitor
• 12V-2A Power Supply
• Operating Instructions
• Sun Hood
Supplied mounting screws:
• KM2.5*6MM x4 (used for Marshall base plate Part# 0032-1308A)
• PM2.5*12MM x4 (used for Marshall VM mount Part# 0032-1301A for IDX battery)
• PM4*6MM x4 (used for VESA mount screw holes)
Inspect the unit for any physical damage that may have occurred during shipping. Should there be
any damage, immediately contact Marshall Electronics at (800) 800-6608.
If you are not located within the continental United States, call +1 (310) 333-0606.
Connections, Power-On and Initial Setup
a. Plug the power supply into an AC power source (100-240 V @ 50/60 Hz).
b. Attach the Power connector to the back of the monitor.
c. Connect the required cables for video signal input and output.
d. Press the Power button to turn the unit on, then press Input to select either HDMI or SDI source
as derived.
