PARTS BREAKDOWN
REF # DESCRIPTION PART# Quantity
1 HANDLE BASE R4529 1
2 #3 PHILLIPS FLAT HEAD SCREW, 1/4"-20 X 1 1/2" WR1386 2
3 WING NUT, 1/4"-20 WR1382 2
4 3/16" HEX DRIVE FLAT HEAD SCREW, 5/16”–18 X 1 1/4" WR1383 2
5 #2 PHILLIPS FLAT HEAD SCREW, 10-24 X 3/4" WR1384 4
6 #3 PHILLIPS FLAT HEAD SCREW, 1/4"-20 X 2 1/2" WR1385 4
7 PLASTIC CAP WL710 2
8 BLADE WX2417 1
9 SLIP-ON FOOT, 3/4" WK219 2
10 COMPRESSION SPRING WX2424 2
11 SET SCREW, 10-24 X 3/16" WR1377 2
12 CAM LOCKING PIN WU904 1
13 #2 PHILLIPS PAN HEAD SCREW, 1/4"-20 X 1/2" WR1158 5
14 #3 PHILLIPS PAN HEAD SCREW, 1/4"-20 X 3/4" WR1378 2
15 EXCENTRIC CAM WX2425 2
16 ANVIL BEAM R4525 1
17 GUIDE ROD WU903 2
18 BLADE BEAM R4526 1
19 CAM BAR R4527 1
20 CAM PIN WU905 2
21 SPRING PIN, 3/8" DIA X 1 1/4" LONG WR1379 2
22 BED BRACE EXTRUSION WC921 2
23 #3 PHILLIPS PAN HEAD SCREW, 1/4"-20 X 1" WR1380 4
24 #2 PHILLIPS FLAT HEAD SCREW, #10 X 1" LONG WR1381 3
25 LEG R4531 1
26 ADHESIVE RULE WX2426 1
27 BED WL708 1
28 SPRING BUTTON WT173 1
29 EXTENSION HANDLE R4528 1
30 SOFT GRIP WT507 1
31 BED FENCE R3944 1
32 END CAP WL741 1
