© Martin Engineering GmbH 28 M3625UK-10/15
Installation
10. Tighten the arresting screws (1, Fig. 21).
11. Place the conveyor belt again on the trough roller station.
Fig. 21: Tighten the arresting screws
Fig. 22: Checking the mobility
NOTE
Ensure that the guide unit (1, Fig. 22) and the entire unit can be
moved freely. The freedom of movement should not be restricted,
otherwise the tracker does not work properly.
