Installation
12. Insert the sensor roller unit in the guide unit (Fig. 23).
13. Adjust the sensor roller unit (1, Fig. 24) in such a manner that it
is perpendicular to the conveyor belt and fix it with the arresting
screws (2, Fig. 24).
Fig. 23: Installing the sensor roller unit
Fig. 24: Positioning the sensor roller unit
2
2
1
1
