Martin Tracker Series - Installation Check-list

© Martin Engineering GmbH 30 M3625UK-10/15
Installation
14. Install the sensor roller unit approx. 6 mm from the conveyor
belt edge and secure it with the arresting screws (1, Fig. 25).
Fig. 25: Adjusting the sensor roller unit
6 mm
1
1
6 mm
