MICROSENTRY™ REFRIGERATION MONITOR
43
Service Parts List Three: 6BARM Mechanical
Illus. No. Description Qty. Req. Part No. Service Assembly
1 Baseplate, R-134a Mechanical 1 41005085 42242579
2 Screw 4 41005089
3 Washer 08205115
4 # 1/4-20 Carriage Bolts 4 08205050 42242388
5 Fan Motor Bracket 1 1010002B
6 Screw 2 41003221
7 Tubing Evacuation 1 41001466
8 Dryer, 1/4 x 5/16 x 3/32 1 41001460 42243394
9 “J” Trap 1 41003857 42244921
10 Drip Pan 1 41003667
11 Tape 1 41003693
12 Copper Tube, .312OD x 4.50 1 41003637
13 Condenser, R-134a 1 41003609 42242082
14 Fan Shroud 1 41003626 42241349
15 Tinnerman Nut 1 41000130
16 Tubing - 14 Long 1 41000445
17 Fan Blade #FV600CW30S38 1 41003616 42242015
18 Silencer 1 M000101A
19 Fan Motor, 115V/60Hz 1 41006539
20 Grommet 4 41007224
21 Sleeve 3 41007225
22 Flat Washer 3 08204877
23 Lock Nut 3 08205051
24 Tecumseh Compressor 1 41007131 42242388
25 Overload 1 41007220 42245133
26 Compressor Cover 1 41007221 42245132
27 Screw 1 41005022
28 PTC Relay 1 41007219 42245131
29 Screw 1 41005086
30 Ground Wire 1 41001401
