Signal Description
Pin Description
Table 1: Media Dependent Interface
117-TFBGA
Pin #
96-aQFN
Pin #
128-PQFP
Pin #
Pin Name Pin
Type
Description
N1
N2
A16
A17
41
42
MDI[0]+
MDI[0]-
I/O, D Media Dependent Interface[0].
In 1000BASE-T mode in MDI configuration,
MDI[0]± correspond to BI_DA±.
In MDIX configuration, MDI[0]± correspond
to BI_DB±.
In 100BASE-TX and 10BASE-T modes in
MDI configuration, MDI[0]± are used for the
transmit pair. In MDIX configuration,
MDI[0]± are used for the receive pair.
MDI[0]± should be tied to ground if not used.
N3
N4
A18
B16
46
47
MDI[1]+
MDI[1]-
I/O, D Media Dependent Interface[1].
In 1000BASE-T mode in MDI configuration,
MDI[1]± correspond to BI_DB±.
In MDIX configuration, MDI[1]± correspond
to BI_DA±.
In 100BASE-TX and 10BASE-T modes in
MDI configuration, MDI[1]± are used for the
receive pair. In MDIX configuration, MDI[1]±
are used for the transmit pair.
MDI[1]± should be tied to ground if not used.
