Marvell 88E1111 - 1.8 128-Pin PQFP Pin Assignments

Doc. No. MV-S105540-00, Rev. A
Page 40 Document Classification: Proprietary Information
1.8 128-Pin PQFP Pin Assignment List - Alphabetical by
Signal Name
Pin # Pin Name Pin # Pin Name
31 125CLK 32 INTn
44 AVDD 95 LED_DUPLEX
49 AVDD 100 LED_LINK10
52 AVDD 99 LED_LINK100
59 AVDD 98 LED_LINK1000
64 AVDD 92 LED_RX
104 AVDD 91 LED_TX
114 COL 35 MDC
37 COMA 41 MDI[0]+
88 CONFIG[0] 42 MDI[0]-
87 CONFIG[1] 46 MDI[1]+
86 CONFIG[2] 47 MDI[1]-
82 CONFIG[3] 56 MDI[2]+
81 CONFIG[4] 57 MDI[2]-
80 CONFIG[5] 61 MDI[3]+
79 CONFIG[6] 62 MDI[3]-
115 CRS 33 MDIO
2DVDD 50NC
6 DVDD 36 RESETn
12 DVDD 39 RSET
17 DVDD 7 RX_CLK
23 DVDD 4 RX_DV
27 DVDD 8 RX_ER
78 DVDD 3 RXD0
85 DVDD 128 RXD1
90 DVDD 126 RXD2
96 DVDD 125 RXD3
117 DVDD 124 RXD4
118 DVDD 123 RXD5
14 GTX_CLK 121 RXD6
53 HSDAC+ 120 RXD7
54 HSDAC- 110 S_CLK+
