Signal Description
128-Pin PQFP Pin Assignment List - Alphabetical by Signal Name
109 S_CLK- 9 VSS
113 S_IN+ 15 VSS
112 S_IN- 21 VSS
107 S_OUT+ 22 VSS
105 S_OUT- 38 VSS
77 SEL_FREQ 40 VSS
70 TCK 43 VSS
67 TDI 45 VSS
72 TDO 48 VSS
69 TMS 51 VSS
68 TRSTn 55 VSS
10 TX_CLK 58 VSS
16 TX_EN 60 VSS
13 TX_ER 63 VSS
18 TXD0 65 VSS
19 TXD1 66 VSS
20 TXD2 83 VSS
24 TXD3 84 VSS
25 TXD4 93 VSS
26 TXD5 94 VSS
28 TXD6 101 VSS
29 TXD7 102 VSS
5 VDDO 103 VSS
11 VDDO 106 VSS
30 VDDO 108 VSS
122 VDDO 111 VSS
73 VDDOH 116 VSS
89 VDDOH 119 VSS
97 VDDOH 127 VSS
34 VDDOX 74 VSSC
71 VDDOX 76 XTAL1
1 VSS 75 XTAL2
1.8 128-Pin PQFP Pin Assignment List - Alphabetical by
Signal Name (Continued)
Pin # Pin Name Pin # Pin Name
