Marvell 88E1111 - 2.6 128-Pin PQFP Package Dimensions

Doc. No. MV-S105540-00, Rev. A
Document Classification: Proprietary Information Page 49
Package Mechanical Dimensions
128-Pin PQFP Package
2.6 128-Pin PQFP Package
0.5 Basic
0.25
min
1.6 Nominal
38
39
1
128
64
65102
103
PIN1
INDICATOR
23.20
±
0.20
20.00
±
0.10
14.00
±
0.10
17.20
±
0.20
0.22
±
0.05 0.88
±
0.15
3.40 Max
