Table 17: 96-Pin aQFN Package Dimensions
Controlling Dimension: MM
Symbol MIN NOM MAX
A----0.85
A3 0.020 0.050 0.080
A2 0.640 0.675 0.710
A1 0.120 0.130 0.140
b 0.250 0.300 0.350
b1 0.350 0.400 0.450
D 9.00 BSC
D2 4.700 4.800 4.900
E 9.00 BSC
E2 5.700 5.800 5.900
eT 0.600
eR 0.600
K 0.350
0.400 0.450
K1 0.850
0.900 0.950
L 0.150
0.200 0.250
Tolerances of Form and Position
aaa 0.150
bbb 0.100
ddd 0.050
ccc 0.080
eee 0.080
fff 0.100
